Where garage doors incorporate glazed panels, three door construction depths are available to suit a range of glazing unit specifications.

56 mm door construction accommodates single, double, slimline and vacuum glazing units, with overall unit thicknesses ranging from 4–24mm.

69 mm door construction accommodates double and triple glazed units, with overall unit thicknesses ranging from 14–36mm, including:
4–6–4 (14 mm DGU)
4–12–4 (20 mm DGU)
4–16–4 (24 mm DGU)
4–12–4–12–4 (36 mm triple glazed unit)
78 mm door construction accommodates triple glazed units, with overall unit thicknesses ranging from 36–44mm, including:
4–12–4–12–4 (36 mm triple glazed unit)
4–14–4–14–4 (40 mm triple glazed unit)
4–16–4–16–4 (44 mm triple glazed unit)

Toughened or laminated glass can also be specified where enhanced protection is required without compromising appearance.

Glazing bars
Glazing bars can be specified as either face-applied or true through bars depending on glazing choice, with a range of profiles and detailing to suit both contemporary and period designs.

Our doors are crafted from precision-machined timber sections, ensuring refined, well-proportioned detailing appropriate to the style of the project.
Garage door panels can be configured as vertically/horizontally/diagonally boarded, raised and fielded, flat or recessed panels, with a range of moulding profiles.

Where required, trickle vents are fully concealed through the head of the frame and are invisible on the internal or the external face of the product.

We offer an extensive range of stains and colours, including any shade from popular paint ranges. If you have a specific colour in mind, we can match it.

Working closely with leading component manufacturers, we carefully select high-quality hardware that delivers both excellent performance and refined detailing.

If you have a particular product in mind that is not covered in our ranges, please let us know and we can check compatibility.

Standard Multipoint Locking system*
As standard, garage doors are fitted with KFV AS4540 multipoint lock with hook locking points, providing distributed locking along the height of the door. The secondary leaf is secured with flush bolts.
This system can be operated by key externally and thumbturn internally, removing the need for an external handle if desired.
Optional alternative:
French Door Multipoint Locking System
We offer the Winkhaus FGTE multipoint locking system, with a primary and secondary leaf configuration and double handle operation. Hooks or twin deadbolts engage into the opposing leaf, with shootbolts securing into the head and cill for distributed, high-security locking.

High-Security Locking Options
A range of proprietary high-security locking systems, including full Banham locking sets, can be integrated where specified.
Cremone Bolts
Where doors are internally operated, surface-mounted cremone bolts can be fitted with a central handle operating vertical rods into the head and cill, providing a traditional locking solution, with optional key or thumbturn locking.

3D Adjustable Hinges
Fully adjustable in three planes for precise in-situ alignment, with maintenance-free, low-friction bearings for long-term performance.
Phosphor Bronze Washered Hinges
Traditional butt hinges with phosphor bronze washers for smooth, durable operation and long service life.
Tectus Hinge
Fully concealed hinge system providing a clean, flush appearance with high load capacity and precise adjustability.

Hinges are available in a range of finishes.
Strap Hinges
Cast iron strap hinges by Charles Collinge are available, suited to period properties, or where high-quality traditional styling is desired.

Finish: black-etched primer, ready to paint.
